Power Sprayers (HTP)

Ralli Horizontal Triplex Pump (HTP)

Specifications

Suction Capacity (lpm)	50
Normal Working Pressure	100 - 200 psi
Maximum Pressure	500 psi
Pump Revolution	950
Power (hp)	5 HP
L × W × H (in mm)	340 × 300 × 295
Weight (without oil)	9 kg (approx)

Features

Suitable for large spraying operations in Orchards, Cof fee, ground crops etc.
Sturdy/rugged construction
Heavy duty & efficient sprayer
Stainless steel piston
All working parts are lubricated by oil bath
Aluminum pressure die casting connecting Rod
Control valve assly. With pressure regulator, by pass
Pulsation free spray
Develop pressure up to 500 psi max.

GENERAL INSTRUCTION

Ralli RTP-50 HTP horizontal triplex power sprayer unit, developing 500 PSI (35 Bar) pressure, supplied with pulley, glycerin filled pressure gauge, by pass cum pressure regulator valve, by-pass hose & suction hose with strainer
